Building a Live Preview in Livewire: Morphing an Iframe Without Breaking Alpine

Building a Live Preview in Livewire

A page builder needs a preview that updates as you type. The naive version is easy: bind the settings form to a Livewire component, re-render the page below it, done. That works until the page you are previewing has its own CSS, its own Alpine components, and its own Livewire components. Then the preview and the editor start fighting over the same document.

I ended up putting the preview in an iframe. This post is about why, and about the three things that broke once I did.

Why an iframe

The preview is not a widget. It is the customer's actual page, rendered by the same Blade views that serve it in production. That means it brings:

• Its own stylesheet. The site's CSS is written for the site, not for a panel. Tailwind preflight alone will reset your editor's typography if they share a document.
• Its own viewport. Device previews are a width on the iframe, and media queries answer correctly, because the iframe is the viewport. Simulating that with a scaled div means every @media rule lies to you.
• Its own JavaScript. Sections can be interactive. Two Alpine instances in one document is a bad afternoon.

An iframe buys isolation on all three. The price is that you no longer have a function call between the editor and the page. You have a message bus.

Section-level refresh, not page reload

The obvious implementation of "the preview updates" is to reload the iframe on every change. Do not do this. Reloading loses scroll position, loses any interactive state inside the page, and flashes. On a settings panel where someone is dragging a colour picker, it is unusable.

Instead the parent sends the new HTML for one section, and the iframe patches it in:

on(MessageType.SectionRefresh, (env) => {
  const data = env.data as { sectionId?: unknown; html?: unknown };
  if (typeof data.sectionId !== 'string' || typeof data.html !== 'string') return;
  // ...find the section by id, morph the new HTML into it
});

Patching means diffing, and for diffing I use morphdom. It walks the old and new trees and applies the minimum set of DOM changes, so nodes that did not change are never touched. Scroll position survives. Focus survives. An open dropdown in an untouched section survives.

That is where the trouble starts.

Problem 1: morphdom must not diff into a Livewire component

Livewire owns the DOM of its components. It keeps a snapshot on the root element and reconciles against it. If morphdom reaches inside and rewrites nodes, Livewire's next round trip disagrees with reality and you get stale state, dead click handlers, or an outright error.

So the rule is: when the diff reaches an element with wire:id, stop diffing and swap the whole root.

if (from.hasAttribute('wire:id')) {
  swapLivewireRoot(from, to);
  return false; // tell morphdom not to descend
}

The swap has to be surgical too. Replacing the node unconditionally would destroy a live component every time any sibling changed. Livewire bookkeeping attributes change on every response even when the rendered output is identical, so comparing the raw nodes is useless. Strip those attributes first, and only swap if the visible markup actually differs:

const LIVEWIRE_STATE_ATTRS = ['wire:id', 'wire:snapshot', 'wire:effects'];

function swapLivewireRoot(from: Element, to: Element): void {
  if (stripLivewireState(from).isEqualNode(stripLivewireState(to))) return;
  (window as WindowWithAlpine).Alpine?.destroyTree?.(from);
  from.replaceWith(to);
}

Alpine.destroyTree on the old root matters. Without it you leak the component's effects and watchers, and after a few edits you have several invisible copies reacting to the same events.

Problem 2: Alpine's MutationObserver races the diff

Alpine watches the document and initialises anything with x-data that appears. That sounds convenient and is exactly the problem: while morphdom is mid-diff, the tree is in an intermediate state, and Alpine may bind directives against a scope that is about to change.

The case that exposed it for me was a section edited from static to interactive. A wrapper that previously had no x-data suddenly gains one. The observer sees the attribute land, initialises the wrapper, and then the diff continues and rewrites its children. Sometimes the children bound to the new scope, sometimes not.

The fix is to pause the observer for the duration of the patch, then initialise deliberately:

function morphPatch(from: Element, to: Element): void {
  const alpine = (window as WindowWithAlpine).Alpine;
  if (alpine?.mutateDom) {
    alpine.mutateDom(() => morphdom(from, to, morphOptions()));
  } else {
    morphdom(from, to, morphOptions());
  }
}

Alpine.mutateDom runs the callback with the observer disabled. Subtrees that were already Alpine components still get handled correctly inside the diff, because morphdom hands those to Alpine.morph, which works fine while the observer is paused.

Then you initialise what the diff injected, and only what it injected:

function initInjectedRoots(scope: ParentNode): void {
  const alpine = (window as WindowWithAlpine).Alpine;
  if (!alpine?.initTree) return;

  for (const root of collectRoots(scope, '[wire\\:id]')) {
    if ((root as MaybeLivewireEl).__livewire) continue;
    alpine.initTree(root);
  }

  for (const root of collectRoots(scope, '[x-data]')) {
    if ((root as MaybeAlpineEl)._x_dataStack) continue;
    alpine.initTree(root);
  }
}

Two details worth stealing:

• Livewire roots are initialised first. Alpine.initTree is also what registers a Livewire component, through Livewire's init interceptor. Doing those first means a nested x-data inside a Livewire component can resolve $wire, and is already marked as initialised when the second loop runs.
• Already-initialised roots are skipped by checking _x_dataStack (Alpine) and __livewire. Nested roots are skipped for free, because an ancestor's initTree runs first in document order and marks the whole subtree. Nothing gets bound twice.

Problem 3: injected script tags never run

This one is in the HTML spec rather than in any library. A <script> inserted through innerHTML or through a DOM diff is not executed. morphdom will happily put your script tag in the document, and the browser will ignore it.

If your sections can carry inline scripts, you have to re-spawn them by hand, and mark them so later diffs do not run them again:

function patchScripts(root: ParentNode): void {
  const scripts = root.querySelectorAll('script');
  scripts.forEach((oldScript) => {
    if (oldScript.dataset.fcRan === '1') return;
    if (oldScript.src && oldScript.dataset.fcAlwaysRerun !== '1') {
      oldScript.dataset.fcRan = '1';
      return;
    }
    const fresh = document.createElement('script');
    for (const attr of Array.from(oldScript.attributes)) {
      fresh.setAttribute(attr.name, attr.value);
    }
    fresh.textContent = oldScript.textContent;
    fresh.dataset.fcRan = '1';
    oldScript.replaceWith(fresh);
  });
}

External scripts get marked but not re-fetched, because re-running a third party embed on every keystroke is its own kind of bug.

Bonus: acknowledge, don't assume

One more thing that is obvious in hindsight. When the editor adds a new section and wants to scroll to it, the scroll message often arrives before the iframe has rendered that section. The element does not exist yet, so the scroll silently does nothing.

Rather than guessing a delay, have the iframe answer:

bus.on(MessageType.SectionScrollResult, (data) => {
  const payload = data as { sectionId?: unknown; found?: unknown };
  if (typeof payload.sectionId !== 'string') return;
  if (payload.found === true) completePendingSectionScroll(payload.sectionId);
});

The parent retries every 150ms up to a limit, and stops the moment the iframe reports found: true. Any cross-document protocol you build this way ends up needing acknowledgement somewhere. Better to design for it than to sprinkle setTimeout around.

What I would tell myself at the start

The iframe is the easy decision. The hard part is that you are now running someone else's JavaScript inside a document you are rewriting underneath it, and the three frameworks involved all assume they are the only thing mutating the DOM. Livewire assumes it owns its subtree. Alpine assumes it will see mutations. The browser assumes injected scripts are not meant to run.

Respect each of those assumptions explicitly and the preview becomes boring, which is what you want from a preview.

I build this into FilamentCraft, a commercial page builder for Filament, so the code above is from a real product rather than a sample. If you want to poke at the result, the demo drops you straight into the editor with no signup.
